Kit for Rooms up to 120 m³ — Aerosol Fire Suppression System AGS-8/2 and SEP-1a

The automatic aerosol fire suppression kit is used to protect rooms where total flooding fire suppression is required without the use of water or foam. The core component of the kit is the AGS-8/2 fire-extinguishing aerosol generator, designed to protect a semi-sealed room with a volume of up to 124 m³. For practical use, the kit is recommended for rooms with a volume of up to 120 m³.

When the Sep1A automatic activation unit is triggered, an activation impulse is supplied to the generator. The solid aerosol-forming charge ignites, and the combustion products pass through the generator nozzle and enter the protected room as a gas-aerosol mixture. The labyrinth cooling system provides preliminary mixing of the aerosol with air and reduces the temperature of the discharged jet.

Kit contents

• AGS-8/2 aerosol fire suppression generator;

• Sep1A automatic activation unit.

Main AGS-8/2 specifications

• Maximum protected volume: up to 124 m³ in a semi-sealed room;

• Recommended room volume for the kit: up to 120 m³;

• Generator weight: 19.5 kg;

• Aerosol-forming charge mass: 6.9 kg;

• Operating time: 170 seconds;

• Dimensions: 270 × 352 × 300 mm;

• Generator activation time: less than 1.5 seconds;

• Operating temperature: from −50 to +50 °C;

• Relative humidity at +25 °C: up to 98%;

• Manufacturer’s warranty: 18 months;

• Operating life: 5 years;

• Service life: 10 years.

System effectiveness depends on the volume, airtightness, and specific features of the protected room. Before installation, a design calculation must be carried out and the optimal equipment installation location must be determined.
